1. 1. Keep the GPS mark side up and the arrow pointing in the direction of the aircraft
nose, otherwise it will not fly normally.
2. 2. Please try to keep no tall buildings around and no trees, otherwise it will affect the
GPS module.
3. 3. The compass is a magnetic sensitive device and should be kept away from strong
magnetic fields, electric fields, and electromagnetic fields (such as wires).
4. The installation needs to select the appropriate GPS installation location to avoid
interference with the compass during operation.
Start the Installation
Important: Strictly follow the provided guidelines. Failure to do so may lead to
unexpected flight behavior or serious accidents.
Install FC
The FC is facing up and parallel to the fuselage，Mounting mark points to the
head direction，Center position as close as possible to the center of gravity of the
aircraft，Then use double-sided tape to fix it to the body.
Install GPS Module
The GPS
module is horizontally parallel
to the fuselage. GPS installation direction as
shown,fix the GPS to the mount with double-sided tape，The fixing seat is fixed on
the tail pipe by double-sided tape and cable tie. After installation, try to ensure that
the GPS module is level with the aircraft fuselage, the GPS is fixed firmly, and the
outlet and the nose are kept level.
GPS use requirements:
H1
