3.4 Approvals
Product approvals for hazardous locations
Pump Approval
• 3069.070
• 3069.090
• 3069.190
• 3069.770
• 3069.890
European Norm (EN)
• ATEX Directive FM18ATEX0006X
• EN 60079-0:2012/A11:2013, EN 60079-1:2014, EN ISO 80079-36:2016,
EN ISO 80079-37:2016
•
II 2 G Ex db h IIB T4 Gb
•
II 2 G Ex db h IIB T3 Gb
IEC
• IECEx scheme IECEx_FMG_17.0036X
• IEC 60079-0:2011, IEC 60079-1:2014
• Ex db IIB T3 Gb
• Ex db IIB T4 Gb
FM (FM Approvals)
• Explosion proof for use in Class I, Div. 1, Group C and D
EN approval plate
This illustration describes the EN approval plate and the information that is contained in
its fields.
1
2
3
5
6 7
8
9 10
11
12
13
14
WS003972C
4
15
1. Approval
2. Approval authority and
Approval number
3. Approved drive unit
4. Cable entry temperature
5. Stall time
6. Starting current or Rated
current
7. Duty class
8. Duty factor
9. Input power
10.Rated speed
11.Additional information
12.Maximum ambient temperature
13.Serial number
14.ATEX marking
15.Country of origin
IEC approval plate
This illustration describes the IEC approval plate and the information that is contained in
its fields.
International Norm; not for EU member countries.
1
2
3
5
6 7
8
9 10
11
12
13
14
4
WS001279D
15
1. Approval
2. Approval authority and
Approval number
3. Approved drive unit
4. Cable entry temperature
5. Stall time
6. Starting current or Rated
current
7. Duty class
8. Duty factor
9. Input power
10.Rated speed
11.Additional information
12.Maximum ambient temperature
13.Serial number
14.ATEX marking
15.Country of origin
3 Product Description
Flygt 3069 Installation, Operation, and Maintenance Manual 15
