4.1.2.4 S-installation
S Portable semipermanent, wet well arrangement with hose coupling or flange for
connection to the discharge pipeline.
The pump is intended to operate completely or partially submerged in the pumped
liquid.
4.1.2.5 X-installation
In the X-installation, the pump has no pre-determined mechanical connection. The flange
is drilled.
4.2 Make the electrical connections
4.2.1 General precautions
DANGER: Electrical Hazard
Before starting work on the unit, make sure that the unit and the control panel are isolated
from the power supply and cannot be energized. This applies to the control circuit as well.
WARNING: Electrical Hazard
Risk of electrical shock or burn. A certified electrician must supervise all electrical work.
Comply with all local codes and regulations.
4 Installation
20 Flygt 3069 Installation, Operation, and Maintenance Manual
