Focusrite Clarett 2Pre USB User Manual

16
3. Using the Clarett 2Pre USB as an on-stage mic pre-amp
The Clarett 2Pre USB automatically stores Focusrite Control settings within the hardware. This
feature lets you congure it as a pair of inputs – mic, line or instrument – for use as a stand-alone
device. This allows you to use it on stage in a live environment where no computer connection is
required, for example.
To FOH Mixer
In the example illustrated, a mic and a guitar are connected to the inputs of the Clarett 2Pre USB;
Outputs 1 and 2 go to the main PA system. The performer can adjust the volume of the mic and guitar
separately from the front panel.

Focusrite Clarett 2Pre USB Specifications

General

Gain	57 dB
Control type	Buttons, Rotary
Sample rates	44.1 - 192 kHz
On/off switch	Yes
Phantom power	48 V
Product color	Black
LED indicators	Power, Signal strength, USB
Frequency range	20 - 35000 Hz
Built-in display	No
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1
XLR inputs	2
USB port type	USB Type-C
Digital audio optical out	1
6.35 mm (1⁄4-inch) output	5
DC output voltage	12 V

Weight and Dimensions

Depth	161 mm
Width	210 mm
Height	55 mm
Weight	1360 g
