Focusrite Clarett 8Pre USB User Manual

16
3. Using the Clarett 8Pre USB as a stand-alone mixer
The Clarett 8Pre USB has the ability to store a mix configuration defined in Focusrite Control within
the hardware. This feature lets you configure it – for example, as an on-stage keyboard mixer – using
your computer, and then upload the configuration to the device itself. Then you can use the Clarett
8Pre USB as a simple, rack-mounting mixer as part of your keyboard rig to control the overall mix
of multiple keyboards.
To FOH Mixer
In the example illustrated, three stereo keyboards are connected to the rear panel inputs of the
Clarett 8Pre USB; Outputs 3 and 4 go to the main PA system. The performer can adjust the volume
of the individual keyboards from the front panel; he/she can also independently adjust the level they
hear the mixed keyboards at through the speakers.

Focusrite Clarett 8Pre USB Specifications

General

Gain	57 dB
Control type	Buttons, Rotary
Sample rates	44.1 - 192 kHz
On/off switch	Yes
Phantom power	48 V
Product color	Black
LED indicators	Power, Signal strength, USB
Frequency range	20 - 35000 Hz
Built-in display	No
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Total Harmonic Distortion (THD)	0.001 %
Windows operating systems supported	Windows 10, Windows 7, Windows RT 8.1
USB port type	USB Type-C
USB ports quantity	1
6.35 mm (1⁄4-inch) output	8

Weight and Dimensions

Depth	291 mm
Width	482.5 mm
Height	43.9 mm
Weight	4080 g
