Page #19 background imageLoading...
Page #19 background image
19
CLARETT 8PRE USB TECHNICAL SPECIFICATIONS
Performance Specifications
Configuration
Inputs 18: analogue (8), S/PDIF (2), ADAT (8)
Outputs 8: analogue (4), S/PDIF (2), HP (2)
Mixer Fully assignable 26-in/10-out mixer
Digital Performance
Supported sample rates 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz & 192 kHz
Microphone Inputs
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 118 dB
THD+N <0.001%
Noise EIN <–129 dBu (A-weighted)
Maximum input level +18 dBu at minimum gain
Gain Range 57 dB
Line Inputs
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 118 dB
THD+N 0.001%
Maximum input level +26 dBu at minimum gain
Gain Range 57 dB
Instrument Inputs
Frequency Response 20 Hz - 35 kHz +/-0.5 dB at minimum gain
Dynamic Range 117 dB
THD+N 0.001%
Maximum input level +14 dBu at minimum gain
Gain Range 57 dB
Line & Monitor Outputs
Dynamic Range 118 dB
THD+N 0.0007%
Maximum Output Level (0 dBFS) +18 dBu at minimum gain, balanced line/TRS outputs
Headphone Outputs
Dynamic Range 115 dB (A-Weighted)
THD+N 0.0009%
Maximum Output Level +15 dBu

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Focusrite Clarett 8Pre USB and is the answer not in the manual?

Focusrite Clarett 8Pre USB Specifications

General IconGeneral
Gain57 dB
Control typeButtons, Rotary
Sample rates44.1 - 192 kHz
On/off switchYes
Phantom power48 V
Product colorBlack
LED indicatorsPower, Signal strength, USB
Frequency range20 - 35000 Hz
Built-in displayNo
Mac operating systems supportedMac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Total Harmonic Distortion (THD)0.001 %
Windows operating systems supportedWindows 10, Windows 7, Windows RT 8.1
USB port typeUSB Type-C
USB ports quantity1
6.35 mm (1⁄4-inch) output8
Weight and Dimensions IconWeight and Dimensions
Depth291 mm
Width482.5 mm
Height43.9 mm
Weight4080 g
