Focusrite Clarett 8Pre USB User Manual

20
Physical and Electrical Characteristics
Analogue Inputs Inputs 1 & 2
Connectors Combo XLR sockets: Mic/Line/Inst, on front panel
Mic/Line switching Automatic
Line/Instrument switching via Focusrite Control
Phantom power +48 V switches for inputs 1 to 4, 5 to 8
Analogue Inputs 3 to 8
Connectors Combo XLR sockets: Mic/Line, on rear panel
Mic/Line switching Automatic
Phantom power +48 V switches for inputs 1 to 4, 5 to 8
Analogue Outputs
Main outputs 10 x balanced ¼” TRS jacks (on rear panel)
Stereo headphone outputs 2 x ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level controls
Other I/O
ADAT Input
2 x TOSLINK optical connectors:
8 channels at 44.1/48 kHz
4 channels at 88.2/96 kHz
2 channels at 176.2/192 kHz
S/PDIF I/O 2 x phono (RCA); can be re-assigned to ADAT ports in software
Data connector (to computer) 1 x USB-C™ connector
MIDI I/O 2 x 5-pin DIN sockets
Weight and Dimensions
W x D x H 482.5 mm x 43.9 mm x 291 mm / 19” x 1.73” x 11.46”
Weight
4.08 kg
9.00 lbs

Focusrite Clarett 8Pre USB Specifications

General

Gain	57 dB
Control type	Buttons, Rotary
Sample rates	44.1 - 192 kHz
On/off switch	Yes
Phantom power	48 V
Product color	Black
LED indicators	Power, Signal strength, USB
Frequency range	20 - 35000 Hz
Built-in display	No
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan
Total Harmonic Distortion (THD)	0.001 %
Windows operating systems supported	Windows 10, Windows 7, Windows RT 8.1
USB port type	USB Type-C
USB ports quantity	1
6.35 mm (1⁄4-inch) output	8

Weight and Dimensions

Depth	291 mm
Width	482.5 mm
Height	43.9 mm
Weight	4080 g
