Page #7 background imageLoading...
Page #7 background image
7
20. LINE OUTPUTS 1 to 8 eight balanced analogue line outputs on a 25-pin female D-sub
connector. This connector is always active, and normally carries the outputs of Channels 1
to 8, enabling the Clarett OctoPre to be used as a stand-alone, high quality 8-channel analogue
mic pre. In ADAT > LINE mode, the connector carries the signals applied at the OPTICAL IN
ports [19]. The pinout of the connector follows the common “Tascam” standard for 8-channel
analogue interfaces:
Pin Function Pin Function
1 Output 8 ‘hot’ (+) 14 Output 8 ‘cold’ (-)
2 Output 8 Gnd 15 Output 7 ‘hot’ (+)
3 Output 7 ‘cold’ (-) 16 Output 7 Gnd
4 Output 6 ‘hot’ (+) 17 Output 6 ‘cold’ (-)
5 Output 6 Gnd 18 Output 5 ‘hot’ (+)
6 Output 5 ‘cold’ (-) 19 Output 5 Gnd
7 Output 4 ‘hot’ (+) 20 Output 4 ‘cold’ (-)
8 Output 4 Gnd 21 Output 3 ‘hot’ (+)
9 Output 3 ‘cold’ (-) 22 Output 3 Gnd
10 Output 2 ‘hot’ (+) 23 Output 2 ‘cold’ (-)
11 Output 2 Gnd 24 Output 1 ‘hot’ (+)
12 Output 1 ‘cold’ (-) 25 Output 1 Gnd
13 n/c
21. WORD CLOCK OUT – a BNC connector carrying the Clarett OctoPre’s word clock; this may be
used to synchronise other digital audio equipment forming part of the recording system. The
source of sample clock synchronisation is selected by the SYNC switch [10].
22. WORD CLOCK IN a BNC connector for the connection of an external word clock signal;
select by setting SYNC to WORD. Use this input if you have a master reference clock which
provides synchronisation for all the digital audio devices in your studio.
23. AC mains standard IEC receptacle. The Clarett OctoPre is fitted with a “Universalpower
supply, and will run from any AC mains voltage from 100 to 240 V, at 50 or 60 Hz.
