20
Instrument Inputs
Frequency Response
20 Hz – 20 kHz, +/-<0.04 dB;
20 Hz – 35 kHz, +/-<0.15 dB
Dynamic Range 116 dB (A-Weighted)
THD+N -96.5 dB @ -1 dBFS and minimum gain
Maximum input level 15 dBu
Gain Range 57 dB
Impedance 2.3M �
Line & Monitor Outputs
Frequency Response
20 Hz – 20 kHz, +/-<0.02 dB;
20 Hz – 35 kHz, +/-<0.02 dB
Dynamic Range 124 dB (A-Weighted)
THD+N -106 dB
Maximum Output Level (0 dBFS) 18 dBu
Impedance 68 �
Headphone Outputs
Frequency Response
20 Hz – 20 kHz, <0.06 dB;
20 Hz – 35 kHz, <0.07 dB
Dynamic Range 118 dB (A-Weighted)
THD+N -104 dB
Maximum Output Level 16 dBu
Impedance 5 �
Physical and Electrical Characteristics
Analogue Inputs 1 to 4
Connectors
Combo XLR sockets: Mic/Line/Inst (Inputs 1 & 2); Mic/Line
(Inputs 3 & 4) on front panel
Mic/Line switching Automatic
Line/Instrument switching
(Inputs 1 & 2)
via Focusrite Control
Phantom power +48 V switches for inputs 1 & 2, 3 & 4
Analogue Inputs 5 to 8
Connectors 4 x balanced ¼” TRS jacks, on rear panel
Analogue Outputs
Main outputs 4 x balanced ¼" TRS jacks, on rear panel
Stereo headphone outputs 2 x ¼” TRS jack on front panel
Main monitor output level control
On front panel
Headphones level controls
