PHYSICAL AND ELECTRICAL CHARACTERISTICS
Analogue Inputs 1 & 2
Connectors
“Combo XLR” sockets on front panel; for Line use ¼” TRS
jack, for Inst use ¼” TS jack.
Mic/Line switching Automatic
Line/Instrument switching via front 2 x front panel switches
Phantom power +48V, switchable Chs. 1-4, 5-8 in groups
Analogue Inputs 3 to 8
Connectors “Combo XLR” sockets on rear panel; for Line use ¼” TRS jack.
Mic/Line switching Automatic
Phantom power +48V, switchable Chs. 1-4, 5-8 in groups
Outputs
Analogue outputs 8 x balanced, on rear panel 25-way female D-sub
Other I/O
ADAT I/O
4 x TOSLINK optical connectors:
8 channels at 44.1/48 kHz (both ports)
8 channels at 88.2/96 kHz (Chs 1-4, 5-8)
4 channels at 176.2/192 kHz (Chs 1 & 2, 3 & 4)
Word clock output 2.5V (correctly terminated); BNC connector
Word clock input BNC connector
Weight and Dimensions
W x D x H
482 mm (1U) x 44.5 mm x 286 mm
19.0” (1U) x 1.75” x 11.3”
Weight 4.15 kg (9.15 lbs)
