Digital Synchronisation
A number of synchronisation options are available:
Scarlett OctoPre Dynamic as Clock Source Master via ADAT:
Connect the Scarlett OctoPre Dynamic to the receiving digital device via the ADAT OUT port(s) and
ensure that the receiving device is set to source its clock from its ADAT input, and also that the
sample rates on both devices match.
On the OctoPre, SYNC should be set to INTERNAL and the LED will illuminate.
Scarlett OctoPre Dynamic as Clock Source Master via word clock:
An alternative method to the above is to sync the receiving device to the Scarlett OctoPre Dynamic’s
WORD CLOCK OUT using a BNC cable. In this scenario, the receiving device’s sync source will need
to be set to its external word clock input.
Scarlett OctoPre Dynamic as Clock Source Slave via ADAT:
Connect the Scarlett OctoPre Dynamic’s ADAT OUT port(s) to the receiving digital device’s ADAT
input. Connect the digital device’s ADAT output to one of the Scarlett OctoPre Dynamic’s ADAT IN
ports. On the OctoPre, SYNC should be set to ADAT and the LED will illuminate. Also ensure that
the sample rates on both devices are matched.
Scarlett OctoPre Dynamic as Clock Source Slave via word clock:
Connect the Scarlett OctoPre Dynamic to the receiving digital device via the ADAT OUT port(s) and
connect a BNC cable from the digital device’s word clock output to the OctoPre’s WORD CLOCK IN
connector, also ensuring that the sample rates on all devices match.
