SCARLETT OCTOPRE DYNAMIC
TECHNICAL SPECIFICATIONS
Performance Specifications
(All performance figures are measured to the AES17 standard).
Sample Rates
Supported sample rates 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz, 176.4 kHz & 192 kHz
Microphone Inputs
Frequency Response 20 Hz to 20 kHz, +0.5/-1.5 dB
Dynamic Range 107 dB (A-weighted)
THD+N <0.002%
Noise EIN –127 dBu
Maximum input level +13 dBu
Gain Range 50 dB
Input Impedance 3 kΩ
Line Inputs
Frequency Response 20 Hz to 20 kHz, +0.5/-1.5 dB
Dynamic Range 107 dB (A-weighted)
THD+N <0.002%
Maximum input level +21 dBu
Gain Range 50 dB
Input Impedance 64 kΩ
Instrument Inputs
Frequency Response 20 Hz to 20 kHz, +0.5/-1.5 dB
Dynamic Range 107 dB (A-weighted)
THD+N <0.015%
Maximum input level +13 dBu
Gain Range 50 dB
Input Impedance 1 MΩ
Line & Monitor Outputs
Dynamic Range (Line outputs) 109 dB (A-weighted)
THD+N <0.001%
Maximum Output Level (0 dBFS) +16 dBu
Output Impedance 136 Ω
