20
Physical and Electrical Characteristics
Analogue Inputs
Connectors
“Combo XLR” sockets on rear panel; for Line use ¼” TRS jack,
for Inst use ¼” TS jack.
Mic/Line switching Automatic
Line/Instrument switching
(Chs. 1 & 2 only)
via front 2 x front panel switches
Phantom power +48 V, switchable Chs. 1-4, 5-8 in groups
Outputs
Analogue outputs 8 x balanced, on rear panel ¼” TRS jack sockets
Other I/O
ADAT I/O
4 x TOSLINK optical connectors:
8 channels at 44.1/48 kHz (RH port*)
8 channels at 88.2/96 kHz (Chs 1-4 RH port*, 5-8 LH port*)
4 channels at 176.2/192 kHz (Chs 1 & 2 RH port*, 3 & 4 LH port*)
Word clock output 2.5 V (correctly terminated with 75 ohms); BNC connector
Word clock input BNC connector: 5 V into 75 ohms
Weight and Dimensions
W x D x H
482 mm x 44.5 mm x 286 mm
19” x 1.75” x 11.26”
Weight
3.37 kg
7.43 lbs
* ADAT ports as viewed from rear of unit.
