FOG QUADRA 493 9021 - Page 10

E 167 - GB - 6
10
Rue du Pré Neuf - 58440 MYENNES FRANCE
QUADRA
493 9021
493 9031
Fig. 5
SCREW M12 X 20
TOP CABLE
GUIDE
BOTTOM CABLE
GUIDE
Fig. 6
Clearance: 2 to 3 mm
CROSS-MEMBER
BOSS
ADJUSTABLE
TRACK
NUT M 20
LADDER RACK
ROLLER
Approx. 1 mm clearance
(only with cross-member in
bottom position)
Fig. 14
