• Check the columns and the tie-rods under the ends of the fixed track.
• Replace the plastic studs that guide the vertical cross-member cheek plates into the columns, if
they are worn.
• Clean and wipe dry the ladders, then rub them with an oiled rag to protect them from rust.
• Check torque setting of the column anchor bolts.
• Check that the platform is level.
CAUTION: IT IS IMPERATIVE THAT THE WIRE ROPE IS READJUSTED WHENEVER A
MAINTENANCE OPERATION IS CARRIED OUT ON A LADDER RACK.
• Check the pulleys for wear.
• Turn the control knob towards ‘RAISE’ until the wire ropes are taut and then check that none of
the wire ropes have come out of their pulleys.
Check the following on the power-pack unit:
• The tension and condition of the return spring for the LOWER lever. If it is weakened or has
deteriorated, its return will no longer be automatic. If necessary, re-tension or replace the spring.
• The presence of a lead seal on the pressure relief valve. If necessary check its settings.
• In each cross-member end, raise the wire rope sensing roller using a hook to check that it turns
freely and does not have any flats.
Check whether the following parts of the rope safety system are operating correctly:
• The rocker retaining system and adjustment.
• The latches and cams together with their adjustment.
• The wire rope safety switches.
• The upper limit switch.
• The setting and operation of ram safety valve.
Check the following:
• Condition of the flexible conduit.
• Condition and operation of the access ramps.
• Condition and cleanliness of the tracks.
Check that the following are available:
• Moveable chocks (for securing the vehicle onto the platform).
• Safety sign notice.
• Maximum lift load notice.
Lift 493 9031
• Check that the auxiliary lift is level.
• Check that the photocell is adjusted and operates correctly.
• Check the condition of the auxiliary lifting pads.
OVERLOAD TESTS
The European Machinery Directive requires that all lifts are tested under dynamic (+10%) and static (+25%)
overload conditions prior to their commissioning. These tests must be carried out only an authorised
competent person. The result and date of these tests as well as the name, occupation and address of the
person who has carried them out, must be recorded in a log or notebook that includes the identification
details of the lift.
CAUTION: DURING THESE TESTS, THE SETTING OF THE PRESSURE RELIEF
VALVE SHOULD BE ALTERED FOR THE DYNAMIC TEST AND THEN RE-SET.
THE LIFT MUST NOT BE OPERATED DURING THE STATIC TEST.
