Fona XPan 3D Plus - CONTROL PANEL

Operating Instructions
10
3.3. CONTROL PANEL
Unit ON with light on display
READY green light ON when system ready
ALARM red light ON upon alarm message
EXPOSURE key on Hand Switch
X-ray Radiation – Orange Light ON
PROGRAM Selection
INCREASE kV (left side) mA (right side)
DECREASE kV (left side) mA (right side)
PATIENT build: Small, Medium, Large, Extra-Large
LIGHT for alignment ON for 60 s
RETURN Arm Movement
TEST Mode without Radiation
BACK for backward movement and alarm reset
UP carriage movement
DOWN Carriage movement
Arrows for the positioning of the canine laser
