FONA XPan 3D Plus
11
3.4. OPERATING POSITIONS
3.4.1. PANORAMIC EXAMS
x PATIENT ENTRY position
Control panel and X-ray source on the right of the patient and the image
receiver on the left.
x START position
System ready to start the exposure. When the unit reaches the START
position the green light of the READY indicator on the control panel is
turned ON
x PATIENT EXIT position
Control panel and X-ray source on the left of the patient and the image
receiver on the right.
3.4.2. CAPHALOMETRIC EXAMS
x CEPHALOMETRIC EXAMS positions
For Cephalometric exam there is only one position: the Panoramic/3D
sensor is in front of the mirror, the X-ray source in front of the
cephalometric sensor.
