FONA XPan 3D Plus
17
6.6. P6 PROGRAM (Temporo-madibular join TMJ, closed/open mouth)
Two exposures are usually taken with closed and open mouth. (Please refer to “Positioning the patient” paragraph 7.3)
Patient is positioned with bite block under the nose.
Once taken the first set of two images, return the unit.
A second set of two exposures can be taken immediately.
TMJ closed mouth:
x Program duration time approx.: 16 s
x Program exposure time: 4.4 s (2 x 2.2 s)
x Positioning tool: 5, 6 (see §4. Positioning tools)
TMJ open mouth:
x Program duration time approx.: 16 s
x Program exposure time: 4.4 s (2 x 2.2 s)
x Positioning tool: 5, 6 (see §4. Positioning tools)
6.7. P7 PROGRAM (Maxillary sinuses)
x Program duration time approx.: 16 s
x Program exposure time: 12.9 s
x Positioning tool: 5, 6 (see §4. Positioning tools)
