Fona XPan 3D Plus - POSITIONING TOOLS

Operating Instructions
12
4. POSITIONING TOOLS
1 Bite block with chin rest
5 Bite block for TMJ and sinus
exams
2 Chin rest with support for
edentulous
6 Nasal support for TMJ and
sinus exams
3 Bite block
7 Chin rest with support for
3D TMJ exams (left and
right) – Optional
4 Nasal support for
edentulous patients
8 Adjustable Nasion Support+
2 auricular rods
(Cephalometric exams)
