11. MESSAGES
11.1. WARNING MESSAGES
Message
Action required
X-ray generator hot
The tube load for the selected exposure does not fit.
Wait for tube cool down.
CAM init
Wait for completion of initialization procedure.
Adjust Arm Position
The rotating arm is out of position.
Turn the system OFF and manually relocate the arm centrally, then turn the system ON.
Wait PC READY
Computer not connected or the application program is not in acquisition mode. Start the
acquisition program on computer.
11.2. ERROR MESSAGES
ALARM RED LIGHT BLINKING
The ERROR number is shown on the display with the red light blinking.
To reset the error condition, press the BACK key.
Error#
Message
Action required
1
kV reference signal out of range
Switch the unit off. Report to technical service.
2
mA reference signal out of range
Switch the unit off. Report to technical service.
3
Carriage rotation encoder failure
Switch the unit off. Report to technical service.
4
Carriage displacement encoder failure
Switch the unit off. Report to technical service.
5
Carriage rotation sensor failure
Switch the unit off. Report to technical service.
6
Carriage displacement sensor failure
Switch the unit off. Report to technical service.
7
Collimator displacement sensor failure
Switch the unit off. Report to technical service.
8
Motor 3D/Pan sensor failure
Switch the unit off. Report to technical service.
10
Tube-head temperature exceeding limit
Wait for tube cool down.
11
Exposure aborted during irradiation
Restart if termination was requested by the operator.
Call for technical service if termination was spontaneous.
12
Exposure aborted before irradiation
Restart if termination was requested by the operator.
Call for technical service if termination was spontaneous.
13
38 V DC supply out of range
Switch the unit off. Report to technical service.
14
24 V DC supply out of range
Switch the unit off. Report to technical service.
15
15 V DC supply out of range
Switch the unit off. Report to technical service.
16
5 V DC supply out of range
Switch the unit off. Report to technical service.
17
High voltage failure
Switch the unit off. Report to technical service.
19
Exposure time exceeded
Switch the unit off. Report to technical service.
20
Exposure aborted after irradiation
Call for technical service if termination was spontaneous.
21
No tube current
Switch the unit off. Report to technical service.
23
Filament current out of range
Switch the unit off. Report to technical service.
25
Thermal Sensor Failure
Switch the unit off. Report to technical service.
26
Battery fault (low voltage)
Switch the unit off. Report to technical service.
28
Collimator encoder failure
Switch the unit off. Report to technical service.
30
PC - Unit communication failure during exam
Switch the unit off. Report to technical service.
32
Control unit fault
Switch the unit off. Report to technical service.
