Weight
81Kg (carriage), 28Kg (Ceph arm).
Self standing base
Optional on request. Order code 93 600 09000
Panoramic Projections
P1: Adult Standard Panorama: 14.2 s,
P2: Child Panorama: 11.5 s,
P3: Left hemi-arch: 7.3 s,
P4: Right hemi-arch: 7.3 s,
P5: Anterior Teeth: 4.8 s,
P6: TMJ normal occlusion or TMJ mouth opened: 2 x 2.2 s,
P7: Frontal View of Maxillary Sinuses: 12.9 s
3D Volume reconstruction
P8: 3D full arch: 12.3 s
P9: TMJ left: 12.3 s
P10: TMJ right: 12.3 s
Cephalometric exams
P11: Antero-posterior:1.6 s (adjustable)
P12: Latero-lateral: 1.6 s (adjustable)
P13: Carpus: 0.5 s (adjustable)
Anatomical Selection
4 Patient size levels: Small, Medium, Large, Extra Large
kV setting
9 positions in 3 kV steps: 61, 64, 67, 70, 73, 76, 79, 82, 85 kV
mA setting
5 positions according to R10 scale: 4, 5, 6.3, 8, 10 mA
mAs setting (Only for Ceph)
14 positions (10mA constant): 2, 2.5, 3.2, 4, 5, 6.3, 8, 10, 12, 16, 20, 25,
32, 40
Source-Image Receptor distance
Pan/3D side:51.9 cm /20.43”
Caphalometric side: 165,8 cm / 65,27’’
Reproduction scale
Pan image at receptor’s plane is approximately 27% higher than real size
(vertical magnification on adult standard profile 1.27:1 approximately)
Cephalometric images at receptor’s plane is approximately 10% higher
than real size (vertical magnification is approximately 1.27:1)
Aiming lights:
Type
Class I LASER beam
Wavelength
650 nm
Output Power
< 0.15 mW at 100 mm
Reference planes
Median Sagittal Vertical, canine and Frankfurt Horizontal planes
Pulse duration
60 s
Image receptor Pan/3D:
Type
CMOS sensor
Active area
13 x 13 cm
Effective pixel size
100 micron
Spatial resolution
5 lpp/mm
A/D conversion
14 bits
Computer interface
2 Ethernet cables
Resulting image format Pano
About 3000x1300 pixels
Image receptor Ceph:
Type
Phosphor plate Flat panel
Active area
About 24 x 30 cm
A/D conversion
16 bits
Computer interface
2 Ethernet cables
Monitor
Minimum size: 19 inches wide
Recommended size: 24 inches wide
Minimum contrast ratio: 500:1
Minimum resolution: 1024x768
Recommended resolution: 1680x1024
Environmental data
Operating conditions
Temperature: from 10 to 40 °C
Humidity: from 30 to 75%
Pressure: from700 to 1060 hPa
Transport and storage
Temperature: from –10 to +50 °C
Humidity: from 20 to 80%
Pressure: from 500 to 1060 hPa
