FONESTAR MPX-4088 - TECHNICAL SPECIFICATIONS MPX-4088; CHARACTERISTICS; INPUTS AND OUTPUTS; CONTROLS AND RESPONSE

TECHNICAL SPECIFICATIONS
MPX-4088
CHARACTERISTICS Audio matrix with 8 analogue input channels to 8 output zones.
4 configurable input/output digital channels for use with controls mod. MPX-
4
00MIC, MPX-410ES, MPX-430VS.
Optional zone controls mod. MPX-420V and MPX-430VS for selection of program
b
roadcast in the zone.
PC control software.
LED indicators for power, bus occupation, signal and failure.
LCD information display.
Microphone with priority and optional zone selection mod. MPX-400MIC.
Compatible with DANTE.
INPUTS 8 balanced line, euroblock 6,800 Ω, 7.74 Vrms maximum
2 RD ports, for mod. MPX-420V, MPX-430VS, MPX-410ES, MPX-400MIC or MPX-
440X, RJ-45
1 RC-Net port for matrix interconnection, RJ-45
1 LAN port for connection to local area network, RJ-45
OUTPUTS 8 balanced line, euroblock 240 Ω, 7.74 Vrms maximum
2 RD ports, for mod. MPX-420V, MPX-430VS, MPX-410ES, MPX-400MIC or
MPX-440X, RJ-45
1 link, switchable RC-Net, RJ-45
RS-232 Port, euroblock
CONTROLS PC control software (input and output routing, DSP functions, equalization, noise
gates, compressor, gain control, etc.)
TCP/IP and RS-232 protocol for integration with other systems
RESPONSE 20-20,000 Hz ±1.5 dB
DISTORTION Harmonic: < 0.01%
S/N RATIO Microphone > 102 dB
Lines> 107 dB
PHANTOM 48 V in inputs 1 to 8, selectable with software
PRIORITY Microphone with optional zone selector mod. MPX-400MIC
Inputs 1 to 8 through level, selectable with software
POWER SUPPLY 100-240 V AC, 50/60 Hz, 80 W
DIMENSIONS 483 x 44 x 256 mm depth. 1 U 19" rack
OPTIONAL MPX-400MIC: microphone with zone selector
MPX-410ES: audio input/output control
MPX-420V: zone control
MPX-430VS: zone control with stereo output
MPX-440X: RD port extender
MPX-450D: DANTE module
