MPX-430VS
CHARACTERISTICS Volume control with two balanced audio outputs and zone allocation for audio
matrix mod. MPX-4088.
Connection to RD ports.
Connection to the matrix via RJ-45, Cat 5e cable.
LCD display with volume level information for the selected output.
INPUTS 1 RD port for connection to matrix MPX-4088, RJ-45
OUTPUTS 2 balanced line, euroblock, 240 Ω, 7.74 V, assignable to digital channels 9/10 or
11/12.
CONTROLS Volume control and zone allocation
CONNECTION RJ-45, Cat 5e cable
POWER SUPPLY 24 V DC, 100 mA, RD port
DIMENSIONS 147 x 86 x 47 mm depth
ACCESSORIES Surface box
MPX-440X
CHARACTERISTICS 4 RD port extender for audio matrix mod. MPX-4088.
Connections via RJ-45, Cat 5e cable.
LED power and connection indicators for each port.
INPUTS 1 RD port for connecting to matrix MPX-4088, RJ-45
OUTPUTS 1 RD audio port for connecting mod. MPX-400MIC, MPX-410ES or MPX-
420VS, RJ-45
3 RD control ports for connecting mod. MPX-420V, RJ-45
CONNECTION RJ-45, Cat 5e cable
POWER SUPPLY 24 V DC, 1 A, euroblock
DIMENSIONS 196 x 44 x 135 mm depth
MPX-420V
CHARACTERISTICS Remote volume and zone allocation control for audio matrix mod. MPX-4088.
Connection to the matrix via RJ-45, Cat 5e cable and link for connection of more
MPX-420V in series.
LCD display with volume level information for the selected output.
INPUTS 1 RD port for connection to matrix MPX-4088, RJ-45
OUTPUTS 1 link, RJ-45
C
ONTROLS
V
olume and zone allocation control
CONNECTION RJ-45, Cat 5e cable
POWER SUPPLY 24 V DC, 100 mA, via RD port
DIMENSIONS 147 x 86 x 47 mm depth
ACCESSORIES Surface box
- 30 -
