DRONE ASSEMBLY
PROPELLERS INSTALLATION/REMOVAL
INSTALLATION
Install propeller A and B on the corresponding motor shaft and fix them tightly by rotating as per the
“lock” direction shown on the propellers. Propellers and drone arms are labeled A or B (Fig. 1).
REMOVAL
Hold the brushless motor with the rotor blade changing tool; rotate and remove the propellers as per
the “unlock” direction shown on the propellers (Fig. 2).
PROPELLER GUARD INSTALLATION
Unscrew the two screws from the bottom of the motors, install the guard, replace and tighten the screws.
FIGURE 1
A
A
A
A
B
B
B
B
REMOVE SCREWS SCREW IN PROPELLER GUARD
FIGURE 2
NOTE
• Be sure to install the correct propellers matching A and B
• Be careful with the propellers, as they can be sharp
• Purchase extra propellers at Force1rc.com
