INSTALLATION
POSITION RESTRAINT TABS
*The safety restraint tabs are secured to the unit and tucked underneath the tie down
tracks for shipping purposes. With a 5/32 allen key loosen the 1/4-20 x 1 ½”button head
located at the rear (tailgate end) inside the tie down track. Rotate the restraint tabs 90 degrees
so that the tabs are facing towards the left & right of the bed. Once positioned tighten the bolts
with a 5/32 allen key and 7/16 wrench.
5/32 ALLEN KEY
7/16
7/16
7/16” WRENCH
TIGHTEN TO MANUFACTURE SPECS, 10 FT. LBS.
