FORESIGHT GCQuad - CLUB MARKER APPLICATION; Marker Application Process

Clean the clubface with an
alcohol pad or water
APPLYING CLUB
MARKERS
In order to capture club data
with the GCQuad, club markers
must be applied to the clubface.
To apply markers using the
dispenser (included):
17
Turn the wheel clockwise to
dispense a club marker
DATA CAPTURED WITH 4 MARKERS
• CLUBHEAD SPEED
• SMASH FACTOR
• ATTACK ANGLE
• SWING PATH
• FACE ANGLE
• LOFT
• LIE
DATA CAPTURED WITH 1 MARKER
• CLUBHEAD SPEED
• SMASH FACTOR
• ATTACK ANGLE
• SWING PATH
Place club marker at the desired location
on the clubface, adhesive side down
(see images for correct fiducial placement)
Firmly apply pressure to the marker with your
finger and gently pull the tab away, leaving only
the marker on the clubface
1
2
3
4
18
