Envelope and Insert Specifications
Minimum: 75 g/m² (20 lb bond)
Maximum: 120 g/m² (32 lb bond)
Envelope quality
GFEDCBA
70 g/m290 mm*142 mm10 mm32 mm105 mm229 mmMin. size
1.5 mmB-6 mmA-12
mm**
35 mm54 mm162 mm241 mmMax. size
3.5"5.6"0.40"1.3"4.1"9.0"Min. size
0.06"B-0.24"A-0.47"**1.4"2.1"6.4"9.5"Max. size
* In case of fold only (no insert): height > 120 mm / 4.7". If the Tri-Fold option is used: height
= 99 mm / 3.9".
** When insert is more than 1 mm (0.04"): A-15 mm / A-0.6".
Remarks:
Maximum insert specifications are based on single sheets. When multiples are handled,
more room inside the envelope is needed depending on the application. The specification
