Foscam D4Z User Manual

110
More FAQs are available here:
https://www.foscam.com/faqs/index.html
5.2 Default Parameters
Default network parameters
IP address: obtain dynamically
Subnet mask: obtain dynamically
Gateway: obtain dynamically
Username and password
Default admin username: admin with a random password
5.3 Specification
Image Sensor
Sensor
High Definition Color CMOS Sensor
Display Resolution
4.0MegaPixels
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
Glass Lens
Focal Length
f: 2.8-12mm
Aperture
f: 2.8-12mm
Angle of View
Diagonal : 36°~126°°
Video
Image Compression
H.264
Image Frame Rate
20fps（2K）/11fps（720P）/, downward adjustable
Resolution
4M(2560* 1440), 3M(2304*1296),
1080P(1920x1080),720P(1280 x 720), VGA(640 x 480),
QVGA(320 x 240)
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are
adjustable
Flip Image
flip and mirror
Infrared Mode
Automatic and manual
IR Range
4pcs IR-LEDs, night vision range up to 20 metres
Network
Ethernet
One 10/100Mbps RJ45 port
Remote Access
P2P
Data Rate
IEEE802.11b: 11Mbps(Max.);
IEEE802.11g: 54Mbps(Max.);
IEEE802.11n: 150Mbps(Max.).
IEEE802.11ac: 433Mbps(Max.)
Wireless Standard
2.4G/5G dual band, IEEE802.11b/g/n/ac
Network Protocol
IP、TCP、UDP、HTTP、HTTPS、SMTP、FTP、DHCP、
RTSP、ONVIF

Foscam D4Z Specifications

General

Resolution	4MP (2560 x 1440)
Connectivity	Wi-Fi, Ethernet
Audio	Two-way audio
Weatherproof	IP66
Local Storage	MicroSD card slot (up to 128GB)
Power Supply	DC 12V/1A
Night Vision	Up to 66ft
Smart Features	Motion detection
Operating Temperature	-4°F to 140°F (-20°C to 60°C)
Storage	MicroSD
