28
Figure 4.4
Reboot the camera and clear the log records.
4.2 Basic Settings
This section allows you to configure your camera’s Name, Time, User account and Multi-Camera.
4.2.1 Camera Name
Default alias is anonymous. You can define a name for your camera here such as apple. Click Save to save
your changes. The alias name cannot contain special characters.
Figure 4.5
4.2.2 Camera Time
This section allows you to configure the settings of the internal system clocks for your camera.
Click the page number and go to the
corresponding page to see more logs.
Fill in one page number, click Go button
and go to the corresponding page.
