Interface View
Figure 1.3
1) I/O alarm terminal block
This network camera provides a I/O alarm terminal block which is used to connect to external input / output
device. The pin(there are four number in the terminal block from no. 1 to no. 4) definitions are descripted
below:
This camera supports I/O alarm, you can go to Settings – Alarm – I/O page to configure it.
2) Audio output interface
The jack is used to plug external speakers.
1– input
2- input
3- output
4- output
