Installing a FastIron LS Switch
September 2007 © 2007 Foundry Networks, Inc. 3 - 11
To rack-mount devices:
1. Attach the brackets to the device using the screws provided in the Bracket Mounting Kit.
Figure 3.5 Attaching the brackets
2. Mount the device in the rack, using four rack-mounting screws (not provided).
Figure 3.6 Installing the RPS in a Rack
3. If installing multiple RPS units, mount them in the rack, one below the other, in any order.
Desktop or Shelf Mounting
1. Attach the four adhesive feet to the bottom of the first RPS unit.
Link
Activity
12
3
4
Fan Thermal Power
Link
Activity
12
3
4
Fan Thermal Power
