Foundry Networks FastIron LS 624 User Manual

Hardware Specifications
September 2007 © 2007 Foundry Networks, Inc. 2 - 9
AC Power Supply
The FastIron LS switches include an integrated AC power supply:
• standard IEC type (IEC320) input connector
• operating 85 VAC to 254 VAC input, universal/wide input
Specifications
10GBase-ER SMF LC connector for
XFP module
9 1550 nm up to 40000
(40 km)
10GBase-LR SMF LC connector for
XFP module
9 1310 nm 2 – 10000
(10km)
10GBase-SR MMF LC connector for
XFP module
62.5/125 160 2 – 26
MMF 62.5/125 200 2 – 33
MMF 50/125 400 2 – 66
MMF 50/125 500 2 – 82
MMF 50/125 2000 2 – 300
10GBase-ZR SMF LC connector for
XFP module
9 1550 nm up to 80000
(80 km)
10GBase-ZRD SMF LC connector for
XFP module
9 1530.33 –
1561.42 nm
up to 80000
(80 km)
10GBase-CX4 4X Twinax IB4X n/a n/a 15 m (49.21 ft.)
1. SMF = Single Mode Fiber, MMF = Multi-Mode Fiber
Table 0.13: Specifications for AC Power
Property FLS624 FLS648
Input voltage range 100 - 240 VAC 100 - 240 VAC
Input current < 3 Amps < 3 Amps
Inrush current < 8.5 Amps peak
maximum
< 12 Amps peak
maximum
Power consumption
(without modules)
65 W 85 W
Power consumption
(with all modules)
105 W 120 W
Max output power 156 W 156 W
Table 0.12: Cable length summary table (Continued)
Cable Type
1
Connector Type Core
Diameter
(microns)
Modal
Bandwidth
(MHz*km) or
Wavelength
(nm)
Range (meters)
