Foundry FastIron LS Layer 2 Compact Switch Hardware Installation Guide
5 - 8 © 2007 Foundry Networks, Inc. September 2007
For Temperature, Tx Power, Rx Power, and Tx Bias Current, values are displayed along with one of the following
status values: Low-Alarm, Low-Warn, Normal, High-Warn or High-Alarm. The thresholds that determine these
status values are set by the manufacturer of the XFPs. Table 5.2 describes each of these status values.
NOTE: This function takes advantage of information stored and supplied by the XFP device. This information is
an optional feature of the Multi-Source Agreement standard defining the XFP interface. Not all component
suppliers have implemented this feature set. In such cases where the XFP device does not supply the information,
a “Not Available” message will be displayed for the specific port that the device is installed
Supported Media
The following media are currently available and supported by FastIron GD and LS devices:
•CWDM80
•CWDM100
•LHA
•LHB
• 1000 Base BXD
• 1000 Base BXU
• 100 Base BXD
• 100 Base BXU
• SX2
• 100FX
• 100FX-1R
Table 5.2: Status Value Description
Status Value Description
Low-Alarm Monitored level has dropped below the "low-alarm" threshold set by the XFP manufacturer.
Low-Warn Monitored level has dropped below the "low-warn" threshold set by the XFP manufacturer.
Normal Monitored level is within the "normal" range" set by the XFP manufacturer.
High-Warn Monitored level has climbed above the "high-warn" threshold set by the XFP manufacturer.
High-Alarm Monitored level has climbed above the "high-alarm" threshold set by the XFP manufacturer.
FLS648 Switch#show optic 4
Port Temperature Tx Power Rx Power Tx Bias Current
+----+-----------+----------+------------+-------------------+
4/1 30.8242 C -001.8822 dBm -002.5908 dBm 41.790 mA
Normal Normal Normal Normal
4/2 31.7070 C -001.4116 dBm -006.4092 dBm 41.976 mA
Normal Normal Normal Normal
4/3 30.1835 C -000.5794 dBm 0.000 mA
Normal Low-Alarm Normal Low-Alarm
4/4 0.0000 C 0.000 mA
Normal Normal Normal Normal
