56
EN
STARTING THE TABLE SAW
WARNING: BEFORE SWITCHING ON THE MACHINE BE SURE THAT THERE IS NOT
ANY OBJECT ON THE WORKBENCH, THAT THE RIVING KNIFE IS CORRECTLY
PLACED AND THAT THE PROTECTIVE CAP AND THAT THE BLADE IS ASSEMBLED, IS
NOT DAMAGED AND THAT IT WORKS PERFECTLY.
To start the saw, press the « I » green button (
Fig. 31
).
To stop the saw, push the « O » red button (
Fig. 32
).
The switch of this machine is a undervoltage switch and prevents the start
of the machine in case of recovery of the electrical energy after an
interruption. So, you must press the green button to re-start the saw after an
interruption of the electrical current.
PROTECTIVE THERMAL CUT-OUT
The saw has a protective thermal cut-out which stops the saw in case of overload, in order to avoid to burn the
motor. It is located one the switch’s side.
When it starts, it sets off the switch and stops the saw. Then you must let the machine cool down some
minutes, then press the manual overload reset button and afterwards the green button of the switch to start
again the saw blade again. If it does not start, wait still some minutes and try again.
If the machine does not start, disconnect it from the socket and check the electric cable and the connections.
If the thermal cut-out often starts, it means you are pushing the blade too much or that you are using poor
quality or not sharpened saw blades.
SAW BLADE BRAKING
This tool has a mechanical brake that stops the blade in less than 10 seconds since when you push the button.
Check the efficiency of the brake periodically, and if it does not work take the machine to an after sales service.
LOCK KNOB OF BLADE’S HEIGHT ADJUST HANDWHEEL
This device allows you to lock blade’s height adjust handwheel.
To loosen the knob, turn it anti-clockwise. Use this handle to angle or
adjust the blade. On the contrary, before any cutting operation, be sure
that the knob and the blade’s height adjust handwheel are perfectly
blocked.
