LED REFERENCE CHARTS
CONTROLLER LED REFERENCE
Event Blink Sequence
Battery has been inserted into
controller
LEDs display battery charge level:
1 yellow blink/10-25%;
1 red blink/<10%
Power o System goes to sleep after 5 minutes (no LED indication)
Enter lever pairing mode/after pressing
pairing button
1 green blink every 0.75 seconds
Remote lever pairing scan/waiting for
confirmation
Solid green
Remote lever pairing success 1 green blink every 0.5 seconds for 5 seconds
Remote lever pairing failure 1 red blink every 0.5 seconds for 5 seconds
BLE connected 2 blue blinks
BLE disconnected 3 blue blinks
Valve/motor fault 2 yellow blinks, then a red blink every second
Remote lever low battery 3 yellow blinks every 5 seconds
Controller low battery 2 red blinks every 5 seconds (also indicated through App)
Valve open from pairing button Solid white LED
Valve opened or closed from remote
lever
LEDs display battery charge level:
1 amber blink/10-20%;
1 red blink/<10%
