Chapter 3 BIOS Description
36
vOn-Chip Serial ATA
This option is used to set the On-chip Serial ATA function. When it is set to
Disabled, the function will be disabled; when it is set to Auto, the BIOS will
enable the function automatically; with it set to Combined Mode, four HDDs at
most will be supported; with it set to Enhanced Mode, six HDDs at most will be
supported (for those under Windows 2000 and Windows XP only); with it set to
SATA Only, only the S-ATA HDD can be used.
vSATA PORT Speed Setting
This option is used to set the Serial ATA PORT Speed.
vPATA IDE Mode
When On-Chip Serial ATA set as “Combined Mode”, this option will be modified.
It is used to set the PATA IDE Mode. The available setting values are: Primary,
Secondary.
vSATA Port
This option is used to set the Serial ATA Port.
