5. A message prompts.
Press [Ctrl-Y] to erase the RAID array.
6. Another screen prompts.
Press [Ctrl-Y]. Input 80GB to select the rst
logical drive (LD1) and press [Enter].
7. The selection of LD1 array is completed.
As we want to introduce how to create two logical drives by using the same two hard
drives here, so we will press [↓] to select LD2.
[ Dene LD Menu ]
LD No RAID Mode Total Drv Capacity(GB) Status
LD 1 RAID 0
2 163.99 Functional
LD 2 −−−− −−−− −−−−−−−− −−−−
LD 3 −−−− −−−− −−−−−−−− −−−−
LD 4 −−−− −−−− −−−−−−−− −−−−
LD 5 −−−− −−−− −−−−−−−− −−−−
LD 6 −−−− −−−− −−−−−−−− −−−−
LD 7 −−−− −−−− −−−−−−−− −−−−
LD 8 −−−− −−−− −−−−−−−− −−−−
LD 9 −−−− −−−− −−−−−−−− −−−−
LD10 −−−− −−−− −−−−−−−− −−−−
[↑] Up [↓] Down [ESC] Exit [Enter] Select
Option ROM Utility (c) 2008 Advanced Micro Devices, Inc.
[ Keys Available ]
LD 1 RAID 0 2 79.99 Functional
[ Dene LD Menu ]
Fast Initialization Option has been selected
It will erase the MBR data of the disks,
<Press Ctrl-Y Key if you are sure to erase it>
<Press any other key to ignore this option>
Press Ctrl-Y to Modify Array Capacity or press any
other key to use maximum capacity...
[ Dene LD Menu ]
LD No RAID Mode Total Drv Capacity(GB)
LD 1 RAID 0
2 164.56
Stripe Block: 64 KB Fast Init: ON
Gigabyte Boundary: OFF Cache Mode: WriteThru
Channel :ID Drive Model Compatibilities Capacity(GB) Assignment
1 :Mas HDS728090PLA380 SATA 3G 82.34 Y
2 :Mas WDC WD1200JD-98HBB0 SATA 1.5G 120.03 Y
3 :Mas Hitachi HDT725025VLA3 SATA 3G 250.05 N
4 :Mas ST3320620AS SATA 1.5G 320.07 N
[0-9] Input Capacity [Enter] Save [Backspace] Delete [ESC] exit
Option ROM Utility (c) 2008 Advanced Micro Devices, Inc.
[ Keys Available ]
RAID 0
[ Dene LD Menu ]
[ Drives Assignment ]
Enter array capacity (in GB) here:
To Next Page
