Foxconn G31MXP User Manual

25
3
Award (Phoenix) BIOS is supporting 3 HDD modes : CHS, LBA and Large.
Note: Set to [Auto] , the system can detect the hard disk and select the HDD mode
automatically. Suggest you select this option.
► Floppy A
This option allows you to select which kind of the Floppy Disk Drive is installed in your system.
It can be [360KB, 5.25"], [1.2MB, 5.25"], [720KB, 3.5"], [1.44MB, 3.5"] and [2.88 MB, 3.5"].
► Halt On
This category determines whether or not the computer will stop if an error is detected during
powering up.
► Model Name
This item shows the model name.
► BIOS Version
This item shows the BIOS version.
► CPU Name
This item shows the CPU name installed in you system.
► Memory
This item shows the information of the system memory, determined by POST(Power On Self
Test) of the BIOS.
► MAC Address
This item shows the onboard LAN MAC address.
All Errors Whenever the BIOS detects a nonfatal error, the system will stop
and you will be prompted.
No Errors The system boot will not stop for any errors that may be
detected.
All, But Keyboard The system boot will not stop for a keyboard error; but it will stop
for all other errors.
All, But Diskette The system boot will not stop for a diskette error; but it will stop
for all other errors.
All, But Disk/Key The system boot will not stop for a keyboard or disk error, but it
will stop for all other errors.
CHS For HDD <528MB
LBA For HDD >528MB & Supporting LBA (Logical Block Addressing)
Large For HDD>528MB but not supporting LBA

Foxconn G31MXP Specifications

General

Form Factor	Micro ATX
Chipset	Intel G31
Socket	LGA 775
Memory Type	DDR2
Memory Slots	2
Maximum Memory	4 GB
Expansion Slots	1 x PCIe x16, 2 x PCI
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
Integrated Graphics	Intel GMA 3100
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Video Outputs	1 x VGA
Supported CPUs	Intel Core 2 Quad, Core 2 Duo, Celeron
LAN	Realtek RTL8102EL 10/100 Mbps
