PC Health Status
► Case Open Warning
This item is used to enable or disable case open warning function.
► Shutdown Temperature
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
► Warning Temperature
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
► CPU Vcore/+ 3.3V/+5V/+12V/VDDR
The current voltages are automatically detected and displayed by the system.
► CPU/System Temperature
The CPU/System temperature are automatically detected and displayed by the system.
► CPU Fan/System Fan Speed
The CPU fan/System fan speed are automatically detected and displayed by the system.
► CPU/System Smart Fan Control
This option is used to enable or disable CPU/System smart fan function. Only when this option
is enabled, you can set some correlative parameters.
► PWM Start TemperatureStart Temperature
It allows you set a temperature value from which smart fan starts its operation.
► Start PWM ValueStart PWM Value
It allows you to set an initial PWM value to drive the fan when the temperature reaches Start
value and smart fan begins its operation. The higher PWM value can achieve the faster fan
speed.
► Slope PWM ValueSlope PWM Value
It controls the PWM value being stepped up or down versus temperature changes.
Phoenix - AwardBIOS CMOS Setup Utility
PC Health Status
Case Open Warning [Disabled] Item Help
Shutdown Temperature [Disabled]
CPU Vcore 1.20 V Menu Level ►
+3.3V 3.39 V
+5V 5.02 V
+12V 11.84 V
VDDR 1.79V
CPU Temperature 51
o
C
System Temperature 38
o
C
CPU Fan Speed 2566 RPM
System Fan Speed 0 RPM
CPU Smart Fan Control [Disabled]
PWM Start Temperature [35]
Start PWM Value [64]
Slope PWM Value [2]
Delta Temperature [2]
System Smart Fan Control [Disabled]
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimi�ed Defaults
Disabled

Foxconn G31MXP Specifications

General

Form Factor	Micro ATX
Chipset	Intel G31
Socket	LGA 775
Memory Type	DDR2
Memory Slots	2
Maximum Memory	4 GB
Expansion Slots	1 x PCIe x16, 2 x PCI
Storage Interface	4 x SATA 3Gb/s, 1 x IDE
Integrated Graphics	Intel GMA 3100
Audio	Realtek ALC662 6-Channel HD Audio
USB Ports	8 x USB 2.0 (4 rear, 4 via headers)
Video Outputs	1 x VGA
Supported CPUs	Intel Core 2 Quad, Core 2 Duo, Celeron
LAN	Realtek RTL8102EL 10/100 Mbps
