Smart BIOS
► Smart Power LED
Smart Power LED is a feature built on your motherboard to indicate different states during
Power On System Test (POST). The LED is located at the front panel, and it displays POST
state by different long-short blinking intervals. You can always leave this state enabled.
► Smart Boot Menu
When PC starts, if [Enabled] is selected, a Boot Menu will be automatically displayed to inform
you to select a boot device. If no device is selected, the rst device will be used. If [Disabled]
is selected, then PC will ask you to press [Esc] key to get into Boot Menu. This setting simpli
es multiple boot devices user from pressing [Esc] key to enter boot menu.
► Current CPU Speed
This item displays the current CPU speed.
► Current FSB Speed
This item displays the current Front Side Bus speed.
► Current CPU Multiplier
This item displays the current CPU Ratio.
► Current DRAM Speed
This item displays the current DRAM speed.
Phoenix - AwardBIOS CMOS Setup Utility
Smart BIOS
Smart Power LED [Enabled] Item Help
Smart Boot MenuSmart Boot Menu [Disabled]
Current CPU Speed 1866MH� Menu Level ►
Current FSB Speed 1066MH�
Current CPU Multiplier 7 Smart Debug LED
Current DRAM Speed 800MH� function within Power
LED
↑↓→←:Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help
F5: Previous Values F7: Optimi�ed Defaults
Enabled
System Status Power LED Status Stop Blinking Condition
Normal Always On Always On
No Memory Continue blinking On (1sec.), Off (1sec.) Reboot & Memory OK
No Display Continue blinking On (2sec.), Off (2sec.) Reboot & Display OK
Post Error Message
Quick blinking twice (1/3sec. On, 1/3sec. Off),
one long On (1sec.), continuously.
Enter Setup or Skip
No CPU Fan Continue blinking On (1/2sec.), Off (1/2sec.) Reboot & Fan OK
