Over Memory Frequency Jumper: MEM_OC_1333
When you use the memory which supports 1333/1066, the jumper is used to overclock memory
frequency. and make the memory word at 1333MHz.
Set the jumper to pins 2-3 (as Status 1) , memory frequency will be 1066MHz. This is default
status. Set the jumper to pins 1-2 (as Status 2), memory frequency will be up to 1333MHz.
MEM_OC_1333
Status1
(Default)
Status1
1
2
3
1
2
3
■ To overclock memory up to 1333MHz, you also need to use CPU which supports
1333.
■ As a result of the memory brand and the chip’s difference, we do not guarantee that
the 1066MHz memory you used all can work steadily under 1333MHz.
C
A
U
T
I
O
N
!
