Foxconn G41MD User Manual

Table of Contents
Chapter 1 Product Introduction
Product Specications ..............................................................................2
Layout.......................................................................................................4
Back Panel Connectors ............................................................................5
Chapter 2 Hardware Install
Install the CPU and CPU Cooler ..............................................................8
Install the Memory ..................................................................................11
Install an Expansion Card ......................................................................13
Install other Internal Connectors ............................................................14
Jumpers ..................................................................................................17
Install driver and utility ............................................................................20
Chapter 3 BIOS Setup
Enter BIOS Setup ...................................................................................23
Main Menu..............................................................................................23
System Information ................................................................................25
Advanced BIOS Features.......................................................................27
Fox Central Control UnitFox Central Control Unit .........................................................................29
Advanced Chipset FeaturesAdvanced Chipset Features ...................................................................33
Integrated Peripherals ............................................................................36
Power Management Setup .....................................................................40
PC Health Status ....................................................................................42
BIOS Security Features..........................................................................43
Load Optimal Defaults ............................................................................44
Save & Exit Setup ..................................................................................44
Exit Without Saving ................................................................................44

Foxconn G41MD Specifications

General

Memory channels	Dual-channel
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	8 GB
Supported memory clock speeds	800, 1066, 1333 MHz
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium Dual-Core
Processor system buses supported	533, 800, 1066, 1333 MHz
CPU fan connector	Yes
Number of SATA II connectors	3
Number of Parallel ATA connectors	1
USB 2.0 ports quantity	4
Firewire (IEEE 1394) ports	0
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® G41
Audio output channels	5.1 channels
Motherboard form factor	micro ATX
Motherboard southbridge	Intel ICH7
Supported storage drive interfaces	SATA II
Graphics card	GMA 4500
Parallel processing technology support	Not supported
Networking features	Gigabit Ethernet
BIOS memory size	64 Mbit

Weight and Dimensions

Width	- mm
