Smart BIOS
► Smart Power LED
Smart Power LED is a feature built on your motherboard to indicate different states during
Power-On Self-Test (POST). The LED is located at the front panel, and it displays POST state
by different long-short blinking intervals. You can always leave this state enabled.
► Smart Boot Menu
When PC starts, it will ask you to press [Del] key to enter setup or press [Esc] key to enter
smart boot menu. If [Disabled] is selected, then pressing [Esc] has no function. This also pre-
vents user without password trying to get into your computer through smart boot menu.
► Current CPU Speed
This item displays the current CPU speed.
► Current FSB Speed
This item displays the current Front Side Bus clock.
► Current CPU Multiplier
This item displays the current CPU Ratio.
► Current DRAM Speed
This item displays the current DRAM Speed.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Smart BIOS
Smart Power LED [Enabled] Help Item
Smart Boot Menu [Enabled]
Current CPU Speed : 1.60GHz
Current FSB Speed : 1066MHz
Current CPU Multiplier : 8x Disabled
Current DRAM Speed : 800MHz Enabled
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
Options
[Enabled]
System Status Power LED Status Stop Blinking Condition
Normal Always On Always On
No Memory Continue blinking On (1sec.), Off (1sec.) Reboot & Memory OK
No Display Continue blinking On (2sec.), Off (2sec.) Reboot & Display OK
Post Error Message
Quick blinking twice (1/3sec. On, 1/3sec. Off),
one long On (1sec.), continuously.
Enter Setup or Skip
No CPU Fan Continue blinking On (1/2sec.), Off (1/2sec.) Reboot & Fan OK
