Advanced Chipset Features
► North Bridge Conguration/ South Bridge Conguration
Press <Enter> to go to its submenu.
North Bridge Conguration
► Video Function Congure
Press <Enter> to go to its submenu.
► Memory Remap Feature
This item is used to enable/disable memory remap feature. Its mainly for if you have a 64bit
OS and 4gb of RAM. Basically it allows you to remap the overlapped PCI memory above the
total physical memory.
► DRAM Frequency
This item is used to adjust the DRAM frequency. Select [Auto] for SPD enable mode. You also
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
Advanced Chipset Features
Advanced Chipset Settings Help Item
WARNING: Setting wrong values in below sections Configure North Bridge
may cause system to malfunction. features.
North Bridge Conguration► North Bridge Conguration [Press Enter]
South Bridge Conguration► South Bridge Conguration [Press Enter]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Press Enter]
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
North Bridge Conguration
North Bridge Chipset CongurationNorth Bridge Chipset Conguration Help Item
Video Function Congure► Video Function Congure [Press Enter]
Memory Remap Feature [Enabled]
PCI MMIO Allocation:4GB To 3328MB
DRAM Frequency [Auto][Auto]
Memory Timing by SPD [Enabled]Memory Timing by SPD [Enabled][Enabled]
Memory Hole [Disabled]
Initial Graphics Adapter [PEG/PCI][PEG/PCI]
IGD Graphics Mode Select [Enabled, 32MB][Enabled, 32MB]
IGD GTT Graphic smemory size [No VT mode, 2MB]
PEG Port [Auto]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Press Enter]
