SuperIO Conguration
► OnBoard Floppy Controller
This item is used to enable/disable Floppy Controller.
► Serial Port1 Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 1.
► Serial Port1 Mode
This item enables you to determine the transfer mode of the serial port 1.
► Serial Port2 Address
This item is used to assign the I/O address and interrupt request (IRQ) for the onboard serial
port 2.
► Serial Port2 Mode
This item enables you to determine the transfer mode of the serial port 2.
► Parallel Port Address
This item is used to assign the I/O address for the onboard parallel(or Printer) port.
► Parallel Port Mode
This item is used to assign interrupt request (IRQ) for the onboard parallel (or Printer) port.assign interrupt request (IRQ) for the onboard parallel (or Printer) port. for the onboard parallel (or Printer) port.
► Parallel Port IRQ
This item is used to select the operation modes for the onboard parallel (or Printer) port.
Setting values are: [Normal], [EPP], [ECP] and [EPP+ECP].
► OnBoard CIR Port
This item is used to disable or assign the I/O address for onboard infrared chip.assign the I/O address for onboard infrared chip.onboard infrared chip.
CMOS Setup Utility - Copyright (C) 1985-2008, American Megatrends, Inc.
SuperIO Conguration
SuperIO Configuration Help ItemSuperIO Configuration Help Item
OnBoard Floppy Controller [Enabled] Allows BIOS to Enable
Serial Port1 Address [3F8/IRQ4] or Disable Floppy
Serial Port1 ModeSerial Port1 Mode [Normal] Controller . Controller .Controller .
Serial Port2 Address [2F8/IRQ3]
Serial Port2 Mode [Normal]
Parallel Port AddressParallel Port Address [378]
Parallel Port Mode [Normal]
Parallel Port IRQ [IRQ7]Parallel Port IRQ [IRQ7]
OnBoard CIR Port [Disabled]
↑↓←→:Move Enter:Select +/-/:Value F10:Save ESC:Exit F1:General Help
F9:Optimized Defaults
[Enabled]
