Foxconn H61MXP Series User Manual

PRODUCT INTRODUCTION
2
1-1 Product Specications
CPU Support Intel
®
IvyBridge/SandyBridgeLGA1155Processors
Maxprocessorpowerupto95W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel
®
H61
Memory 2x240-pinDDR3DIMMs
Support up to 16GB of system memory
Dual channel DDR3 1600(IVB)/1333 MHz architecture
Expansion Slots 1xPCIExpress3.0(IVB)/2.0x16slot
1 x PCI Express x1 slot
2xPCIslot
Storage Intel® H61 chipset
-4xSATA2.0connectors(3Gb/sdatatransferrate)
LAN Realtek RTL8111F-CG Gigabit LAN controller
Support 10/100/1000Mbps
Audio RealtekALC662-GR
-HighDenitionAudio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Supportupto8xUSB2.0ports(4rearpanelports,2onboardUSB
headerssupporting4extraports)
SupportUSB2.0protocolupto480Mb/s
Internal
Connectors
1x24-pinATXpowerconnector
1x4-pinATX12Vpowerconnector
4xSATA2.0 connector
2xUSB2.0header(supporting4xUSBdevices)
1xCPUFANheader(4-pin)
1xSystemFANheader(4-pin)
1 x Front panel header
1 x Front audio header
1 x Speaker header
1 x TPM header
1 x INTR header
1 x COM header
1 x Clear CMOS header
1 x ME header
Back Panel
Connectors
1xPS/2Keyboardport
1xPS/2 Mouse port
1xRJ45LANport
1 x VGA port
1 x COM port
1 x Parallel port
4xUSB2.0ports
3 x Audio ports
