BIOS SETUP
37
Health
Version 2.02.1205. Copyright (C) 2012 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
Main F-Center Advanced Boot Power Health Security Save & Exit
Case Open Warning [Disabled]
CPU Temperature : +39 ˚C
System Temperature : +35 ˚C
CPU Fan Speed : 1117 RPM
System Fan Speed : N/A
CPU Vcore : +1.200 V
+3.3V : +3.392 V
+12V SYS : +12.300 V
+5V SYS : +5.097 V
VDDR : +1.740 V
VBAT : +3.328 V
CPU Warning Temperature [Disabled]
CPU Shutdowm Temperature [Disabled]
CPU Smart Fan Control [Disabled]
System Smart Fan Control [Disabled]
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Case Open Warning
Health
►CaseOpenWarning
This item is used to enable or disable case open warning function.
►CPUTemperature
These items show the current CPU temperature detected automatically by the system.
►SystemTemperature
These items show the current System temperature detected automatically by the system.
►CPUFanSpeed
This item shows the current CPU Fan speed detected automatically by the system.
►SystemFanSpeed
This item shows the current system Fan speed detected automatically by the system.
►CPUVcore/+3.3V/+12VSYS/+5VSYS/VDDR/VBAT
TheseitemsshowtheCurrentCPUVcore/+3.3V/+12VSYS/+5VSYS/VDDR/VBATvoltage
detected automatically by the system.
►CPUWarningTemperature
This option is used to set the warning temperature for the system. When the temperature of
CPU is higher than the set value, the motherboard will send out warning information.
►CPUShutDownTemperature
This item is used to set the system temperature upper limit. When the temperature exceeds
the set value, the system will shut down automatically.
This function works only when your operating system is supporting ACPI.
►CPU/SystemSmartFanFunction
This option is used to enable or disable smart fan function. Default value is [Disabled]. Only
when this option is enabled, you can set some correlative parameters. “Smart Fan Automatic
Mode”istheprinciplegureofCPUsmartfanfunctionforyourreference.TheCPUfan/
System fan speed are automatically detected and displayed by the system.
