Foxconn H77MXV Series User Manual

BIOS SETUP
32
Super IO Conguration
Version 2.14.1219. Copyright (C) 2011 American Megatrends, Inc.
Aptio Setup Utility - Copyright (C) 2011 American Megatrends, Inc.
Super IO Configuration
Super IO Chip IT8728
▶ Serial Port 1 Configuration
▶ Parallel Port Configuration
▶ CIR Controller Configuration
→ ←: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Set Parameters of Serial Port
0 (COMA)
Advanced
►SerialPort1Conguration
Press <Enter> to go to its submenu and the following information will be displayed.
►SerialPort
This item is used to enable or disable the serial port.
►DeviceSettings
This item shows the resource assigned to the serial port.
►ChangeSettings
This item is used to select an optimal settings for the serial port.
►ParallelPortConguration
Press <Enter> to go to its submenu and the following information will be displayed.
►ParallelPort
This item is used to enable or disable the parallel port.
►DeviceSettings
This item shows the resource assigned to the parallel port.
►ChangeSettings
This item is used to select an optimal settings for the parallel port.
►DeviceMode
This item is used to change the parallel port mode.
►CIRControllerConguration
Press <Enter> to go to its submenu and the following information will be displayed.
►CIRController
This item is used to enable or disable the CIR Controller.
►ChangeSettings
This item is used to select an optimal settings for the parallel port. Security
