8.Formatnished.Click"OK"tocontinue
copying of RAID driver into this diskette.
9.Checkifthediskettecontainsthedriverles.
Later, when in the process of installing
Windows XP in your RAID system, it will ask
 youtousethisoppydiskettetoprovide
 driverforadditionalspecicdevices,for
example, a RAID device.
10. Install Serial ATA Hard Disks :
10-1. Shut down your computer.
 10-2.InstallSATAharddisksintothedrivebays,connectallpowerandSATAcables.
5-5 BIOS Conguration
1. Enter the BIOS setup by pressing <DEL> key during the POST(Power On Self Test).
2.Setthe“SATAMode”to“RAIDMode”.(PleaserefertoChapter3BIOSSetup)
3.Press<F4>tosavethesettingthenPCwillrebootitself.
5-6 Create RAID in BIOS
1. Enter RAID BIOS Setup
When BIOS is restarted, it will display a message asking you to press <Ctrl>+<I> keys simul-
taneouslytoenterthemainmenuofIntel®RapidStorageTechnologyenterpriseOptionROM
Utility.Pressthe<Ctrl>+<I>toenterCongurationUtility.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9Rw6AID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
  1.CreateRAIDVolume4.RecoverVolumeOptions
  2.DeleteRAIDVolume  5.AccelerationOptions
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
NoneDened.
Physical Devices:
ID Device Model Serial # Size Type/Status(Vol ID)
0
ST3320418AS 9VM8Y4D8 298.0GB Non-RAID Disk
1
ST3160815AS 5RX4M04N  149.0GB Non-RAID Disk
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
1. Create RAID Volume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
