RAID CONFIGURATION
85
3. Delete RAID Volume
1.TakeTryRAID5forexample.Select“2.DeleteRAIDVolume”inmainmenuandpress 
<Enter>.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
  1.CreateRAIDVolume  4.RecoverVolumeOptions
      5.AccelerationOptions
3. Reset Disks to Non-RAID 6. Exit
RAID Volume :
ID Name Level Stripe Size Status Bootable
 0 TryRAID5  RAID5(Parity)64KB 149.1GB Normal Yes
Physical Disks:
Port Drive Model Serial # Size Type/Status(Vol ID)
 0 HitachiHDS72161 PVF904Z21G2JZM 149.0GB Member Disk(0)
1
ST380811AS 5PS1TAGW 74.5GB Member Disk(0)
 2
SAMSUNG HD161HJ  S0V3J9APA30524 149.0GB Member Disk(0)
3
ST380815AS 5RW1CA37  74.5GB Non-RAID Disk
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[DISK/VOLUMEINFORMATION ]
[ MAIN MENU ]
2.DeleteRAIDVolume
[↑↓]-Select[ESC]-Exit[ENTER]-SelectMenu
2.UseUporDownarrowkeytoselecttheRAIDsetyouwanttodelete.HereonlyoneRAID5
is seen, so press <DEL> key to continue.
Intel(R)MatrixStorageManageroptionROMv5.0.0.1011ICH9RwRAID5
Copyright(C)2003-04IntelCorporationAllRightsReserved.
Name Level Drives Capacity Status Bootable
TryRAID0 ID0(Stripe)2 465.8GB Normal Yes
Deleting a volume will reset the disks to non-RAID.
WARNING:ALLDISKDATAWILLBEDELETED.
(This does not apply to Recovery volumes)
[↑↓]-Select[ESC]-PreviousMenu[DEL]-DeleteVolume
Intel(R)RapidStorageTechnology-UptionROM-11.0.8.1204
Copyright(C)2003-11IntelCorporation.AllRightsReserved.
[ HELP ]
[ DELETE VOLUME MENU ]
TryRAID5 RAID5(Parity)3 149.1GB NormalYes
3. After <DEL> key is pressed, the screen appears as below:
 Press<Y>keytoconrmthevolumedeletion.
